SPECIFICATIONS YAMAHA XSR900GP
ENGINE
Type :
890cc , liquid-cooled , DOHC
12-valve , four-stroke , CP3
triple
Bore x stroke :
80mm x 49.7mm
Power :
87.5kW ( 117hp ) @ 10,000rpm
Torque :
93Nm @ 7000rpm
Compression :
11.5:1
Fuelling :
Electronic injection
Clutch :
Wet multiplate clutch , antihopping
and assist clutch
Transmission :
Six-speed , chain drive
CHASSIS
Frame : Aluminium diamond frame , engine as stressed-member Rake / Trail : 25.3 °/ 110mm Swingarm : Aluminium two-sided Suspension : KYB USD fork with spring preload , compression and rebound damping adjustment , 130mm travel front ; Linkagetype KYB monoshock with spring preload , compression and rebound damping adjustment , 131mm travel rear
Brakes : Twin 298mm discs , radial fourpiston calipers front ; 245mm disc , single piston caliper rear ; 6-axis IMU , Lean-sensitive ABS Wheels : Cast aluminium Tyres :
120 / 70ZR17 front ; 180 / 55ZR17 rear
DIMENSIONS
Seat height :
835mm
Wheelbase :
1500mm
Weight ( wet ):
200kg
Fuel capacity :
14 litres
Price :
$ 22,799 ride-away
Contact :
Yamaha NZ
Web :
yamaha-motor . co . nz
