SPECIFICATIONS
KTM 790 Duke
ENGINE
Type:
799cc, liquid-cooled, DOHC, four-stroke
parallel twin
Bore x stroke:
88 x 65.7mm
Compression:
12.7:1
Power (claimed):
77kW (105hp) @ 9000rpm
Torque (claimed):
87Nm @ 8000rpm
Starting system:
Electric
Fuel system:
Electronic fuel injection,
42mm throttle body
Clutch:
Wet, multi-plate, anti-hopping slipper
Transmission:
Six-speed, manual, chain drive
CHASSIS
Type:
Steel trellis space frame,
engine stressed member
Rake/trail: 24°/98mm
Suspension: WP 43mm inverted telescopic fork,
fully adjustable front, 140mm travel;
WP monoshock, preload adjustment,
150mm travel
Brakes:
two 300mm discs, radially-mounted,
four-piston calipers front; single 240mm
disc, two-piston Brembo caliper rear;
switchable ABS
Wheels:
Cast aluminium, tubeless
Tyres:
120/70ZR-17 front; 180/55ZR-17 rear
QUICK QUOTE
DIMENSIONS
Wheelbase:
Seat height:
Weight:
Fuel capacity:
Price:
Contact:
Web:
102 KIWI RIDER
1475mm
825mm
175kg
14 litres
$16,999 plus on the road
KTM New Zealand
www.ktm.com/nz/naked/790-duke/
KTM 790 Duke $16,999
Monthly premium $$63.75
Excess $500
Agreed Value Full Cover premium
including Apparel cover, Roadside
Assistance, Track Day cover, Keys and
Locks cover, Completion of Journey
costs, Salvage Costs. The quoted
premium is based on the following
assumptions: Experienced rider, over
30, living in Auckland, Full NZ Motorcycle
Licence, no claims or convictions within
the last 5 years, private use only.
