KIWI RIDER 03 2020 VOL2 | Page 104
KTM 790 ADVENTURE R
ENGINE
Type:
799cc, liquid-cooled, DOHC, four-stroke
parallel twin
Bore x stroke:
88 x 65.7mm
Compression: 12.7:1
Power (claimed):
70kW (95hp) @ 8000rpm
Torque (claimed):
88Nm @ 6600rpm
Starting system:
Electric
Fuel system:
Electronic fuel injection, 46mm throttle body
Clutch:
Wet, multi-plate, anti-hopping slipper
Transmission:
Six-speed, manual, chain drive
CHASSIS
Type:
Steel trellis space frame, engine stressed
member
Rake/trail: 26.3°/110.4mm
Suspension: WP 48mm inverted telescopic fork, fully
adjustable, 240mm travel front; WP PDS
monoshock, fully adjustable, 240mm travel
rear
Brakes:
2 x 320mm discs, radially-mounted, four-
piston calipers front; single 260mm
disc, two-piston Brembo caliper rear;
Bosch 9.1MP ABS (cornering, off-road,
disengageable)
Wheels:
Spoked, aluminium rims
Tyres:
90/90-21 front; 150/70-18 rear
DIMENSIONS
Wheelbase:
Seat height:
Weight:
Fuel capacity:
Price:
Contact:
Web:
104 KIWI RIDER
1528mm
880mm
189kg (no fuel)
20 litres
$24,499 plus on the road
KTM New Zealand
ktm.com/nz/travel/790-adventure-r/
QUICK QUOTE
KTM 790 ADVENTURE R $24,499
Monthly premium $42.00
Excess $500
Agreed Value Full Cover premium including
Apparel cover, Roadside Assistance, Track
Day cover, Keys and Locks cover, Completion
of Journey costs, Salvage Costs. The
quoted premium is based on the following
assumptions: Experienced rider, over 30, living
in Auckland, full NZ Motorcycle Licence, no
claims or convictions within the last 5 years,
private use only.
